Synergy between in situ and altimetry data to observe and study Northern Current variations (NW Mediterranean Sea)

Alice Carret, Florence Birol, Claude Estournel, Bruno Zakardjian, and Pierre Testor

During the last 15 years, substantial progress has been achieved in altimetry data processing, now providing data with enough accuracy to illustrate the potential of these observations for coastal applications. In parallel, new altimetry techniques improve data quality by reducing land contamination and enhancing the signal-to-noise ratio. Satellite altimetry provides more robust and accurate measurements ever closer to the coast and resolve shorter ocean signals. An important issue is now to learn how to use altimetry data in conjunction with other coastal observing techniques.

Here, we cross-compare and combine the coastal currents provided by large datasets of ship-mounted acoustic Doppler current profilers (ADCPs), gliders, high-frequency (HF) radars and altimetry. We analyze how the different available observing techniques, with a particular focus on altimetry, capture the Northern Current variability at different timescales. We also study the coherence, divergence and complementarity of the information derived from the different instruments considered. Two generations of altimetry missions and both 1 Hz and high-rate measurements are used: Jason-2 (nadir Ku-band radar) and SARAL/AltiKa (nadir Ka-band altimetry); their performances are compared.

In terms of mean speed of the Northern Current, a very good spatial continuity and coherence is observed at regional scale, showing the complementarity among the types of current measurements. In terms of current variability, there is still a good spatial coherence but the Northern Current amplitudes derived from altimetry, glider, ADCP and HF radar data differ, mainly because of differences in their respective spatial and temporal resolutions. If we consider seasonal variations, 1 Hz altimetry captures ∼60 % and ∼55 % of the continental slope current amplitude observed by the gliders and by the ADCPs, respectively. For individual dates this number varies a lot as a function of the characteristics of the Northern Current on the corresponding date, with no clear seasonal tendency observed. Compared to Jason-2, the SARAL altimeter data tend to give estimations of the NC characteristics that are closer to in situ data in a number of cases. The much noisier high-rate altimetry data appear to be more difficult to analyze but they provide current estimates that are generally closer to the other types of current measurements. Thus, satellite altimetry provides a synoptic view of the Northern Current circulation system and variability, which helps to interpret the other observations. Its regular sampling allows for the observation of many features that may be missed by irregular in situ data.

1 Introduction

Radar altimeters allow us to estimate sea surface height (SSH) variations along satellite tracks at regular time intervals. Providing a large number of continuous and accurate observations of the global oceans for more than 25 years, they have progressively evolved into one of the fundamental instruments for many scientific and operational oceanographic applications (Morrow and Le Traon, 2012). The SARAL mission and its first AltiKa Ka-band frequency radar, launched in 2013, has improved the performance of satellite altimetry (Bonnefond et al., 2018). With the launch of Sentinel-3A and B in February 2016 and April 2018, the altimetry constellation was completed by the first instruments always operated in high-resolution mode (commonly called synthetic aperture radar or SAR). These new altimeters provide enhanced along-track resolution and reduced noise in comparison to the conventional nadir-looking pulse-limited Ku-band instruments used since the beginning of the altimetry era. In 2021, the SWOT mission, with its SAR interferometer in Ka-band measuring SSH over 120 km wide swaths, will be a new step forward (, last access: 23 October 2018).

In coastal ocean areas, it is particularly important to monitor sea level variations. About 10 % of the world's population lives in low-elevation coastal zones (Nicholls and Cazenave, 2010) exposed to hazards such as extreme events, flooding, shoreline erosion and retreat. The latter are expected to increase due to the combined effects of sea level rise, climate change and increasing human activities. In coastal regions in particular, we expect a lot of advances from modern altimetry instruments and processing techniques. Indeed, conventional satellite altimetry missions have not been designed for the observation of coastal dynamics. The strongest limitation is the modification of the radar echo in the vicinity of land, but the sea level estimations derived are also impacted by inhomogeneity in the water surface observed by radar and by less accurate corrections. Coastal altimetry measurements are much more difficult to interpret than in the open ocean and need dedicated processing and specific corrections (Gommenginger et al., 2011; Cipollini et al., 2017a). The data resolution is also too low to capture the fine scales of coastal ocean dynamics. As a consequence, most altimetry data collected in coastal zones over the last 25 years have been discarded in altimetry products and/or poorly exploited. A lot of effort has been invested during the last 15 years in the altimetry community to overcome these difficulties, and substantial progress has been achieved on the data processing side (Roblou et al., 2011; Passaro et al., 2014; Valladeau et al., 2015; Cipollini et al., 2017a), starting to provide data with enough accuracy to illustrate the potential of altimetry for coastal applications (Passaro et al., 2016; Birol et al., 2017a; Morrow et al., 2017). Moreover, the use of new altimetry techniques provides more robust and accurate measurements closer to the coast and allows us to resolve shorter spatial scales (Dufau et al., 2016; Morrow et al., 2017). As an example from Birol and Niño (2015), closer than 10 km to the coastline, available SARAL data are still  60 % and only ∼31 % for Jason-2. From Morrow et al. (2017), in summer, SARAL can detect ocean scales down to 35 km of wavelength, whereas the higher noise from Jason-2 blocks the observation of scales less than 50–55 km in wavelength. As a result, the capability of altimetry for the monitoring of coastal ocean dynamics has already been illustrated in a number of studies. Most of them concern shelf and boundary currents (Bouffard et al., 2008; Birol et al., 2010; Herbert et al., 2011; Jebri et al., 2016, 2017). Some others are related to sea level applications (Cipollini et al., 2017a). A more complete review of coastal altimetry applications can be found in Cipollini et al. (2017b) and we can easily predict that the use of this instrument in coastal studies will be largely extended in the next years.

Today, observations used in coastal applications are mainly based on in situ instruments and satellite imagery (sea surface temperature and ocean color images). In order to address the need for monitoring the coastal ocean environment, in situ observing systems gather information in a growing number of regions such as along the Australian and US coasts (, last access: 14 November 2018;, last access: 14 November 2018;, last access: 14 November 2018; see also Liu et al., 2015). Different techniques are often used in synergy, measuring different ocean state parameters on different time and spatial scales. Compared to altimetry, their spatial and/or temporal resolution is much more adapted to detect coastal ocean variability. Nonetheless, in situ observations cover more limited areas and often provide time series that present large gaps, which may be several days (buoy data, high-frequency (HF) radars) to several months (glider, ship data). Moreover, optical imagery is often impacted by clouds and does not provide any direct information on the changes occurring in the water column. The large advantage of satellite altimetry, and the reason for its success in the deep ocean, is that it offers almost global and synoptic observations of the sea level, a geophysical parameter that can be related to ocean circulation and many other dynamical features (eddies, waves, seawater changes). An important issue is now to learn how to use altimetric data in synergy with other coastal observing techniques.

To study the contribution of altimetry amongst other types of coastal ocean measurements, the northwestern Mediterranean Sea (NWMed) represents a laboratory area. First, with a Rossby radius of only ∼10 km, the region is associated with a variety of mesoscale and sub-mesoscale dynamical signals (see below). As a result it represents a challenge for altimetry. Secondly, the number of in situ observations is relatively important in this region, allowing for comparison with independent data. In the NWMed, the main feature of the surface ocean circulation is the Northern Current (called NC hereafter), which is formed in the Ligurian Sea (Taupier-Letage and Millot, 1986) and flows cyclonically along the Italian, French and Spanish coasts. This current presents a marked seasonal variability, with a maximum amplitude from February to April (Sammari et al., 1995; Millot, 1991), and it meanders in a vast range of wavelengths (10–100 km). The mesoscale variability is higher in autumn and winter because of the larger baroclinic instability associated with strong and cold winds (Alberola et al., 1995; Millot, 1991). During the last 10 years, the NC has been intensively monitored by a variety of in situ data (moorings, research vessels, gliders and HF radars) collected from the MOOSE (Mediterranean Ocean Observing System for the Environment) integrated observing system. Despite a width of only 30–50 km, through comparison with acoustic Doppler current profiler (ADCP) data located in the Ligurian Sea, Birol et al. (2010) demonstrated that reprocessed altimetry data are able to capture half of the amplitude of the seasonal NC variability. The altimetry currents have then been used to analyze the regional current variability at seasonal scale. In the Balearic Sea, the reliability of altimetry currents has been verified by direct comparison with currents derived from gliders and HF radars (Bouffard et al., 2010; Pascual et al., 2015; Troupin et al., 2015). These case studies showed that altimetry can depict current signals coherent with the other instruments. Morrow et al. (2017) also showed that some of the large-scale eddies observed by gliders in the NWMed can be captured by altimetry. A more systematic use of altimetry in regional coastal applications requires a better quantitative assessment of its performance near coastlines on daily to interannual timescales.

The general objective of this paper is not only to investigate the accuracy of the velocity fields derived from altimetry data next to the coast at different temporal scales, but also to define its contribution compared to the other coastal ocean observing systems that exist in the region (ship-mounted ADCPs, gliders and HF radars). In this study, we combine all the different available in situ datasets that provide information on currents in the Ligurian–Provençal basin and perform systematic comparisons with currents derived from altimetry at different timescales. In particular, we analyze how the different available observing techniques capture NC variability and the coherence, divergence and complementarity of the information derived. From previous studies, we know that only a small part of the NC variations can be captured by conventional satellite altimetry. Here, we use both the Jason-2 and SARAL/AltiKa missions to investigate the progress made from Ku-band to Ka-band altimetry. We also investigate the potential of experimental 20 and 40 Hz altimetry products to monitor NC variations relative to conventional 1 Hz data.

In this paper, Sect. 2 presents the datasets used and the corresponding data processing. It is followed by an intercomparison between the currents derived from altimetry and from the different in situ datasets, with an analysis of the NC variations observed at different timescales by the different instruments (Sect. 3). Section 4 concludes the paper.

2 Data and methodology

2.1 Satellite altimetry

We use two altimetry missions with distinct characteristics: Jason-2 and SARAL/AltiKa. Jason-2 was launched in June 2008 and provides long time series of data with a 10-day repeat observation cycle. The performance of SARAL is significantly better. With a better signal-to-noise ratio, it resolves smaller spatial scales than Jason-2: ∼40 km against ∼50 km (Dufau et al., 2016; Verron et al., 2018). However, the corresponding time series started only in February 2013 and have a 35-day repeat observation cycle, so they are a priori not really adapted to the monitoring of coastal ocean variability. On the other hand, the SARAL orbit leads to a smaller distance between tracks compared to Jason-2 (Fig. 1). Here we focus only on the SARAL tracks 302, 343 and 887 and on the Jason-2 track 222, providing the closest data from the in situ observations.

For both missions, because it is one of the most often used in coastal altimetry applications, we first used the X-TRACK regional product from the CTOH (, Birol et al., 2017b), processed with a coastal-oriented strategy (Birol et al., 2017a). It consists of time series of 1 Hz sea level anomalies (SLAs) every 6–7 km along the satellite tracks, available from 20 July 2008 to 1 October 2016 for Jason-2 (i.e., 300 cycles) and from 24 March 2013 to 12 June 2016 for SARAL (i.e., 34  cycles). In order to evaluate the skill of the 20 and 40 Hz altimetry measurements of the Jason-2–SARAL altimeters for circulation studies relative to the conventional 1 Hz data, we have also used an experimental high-rate version of these datasets provided by the CTOH (Sect. 3.4). The processing is the same as for 1 Hz SLA, except that the high-rate SLAs are computed from the 20–40 Hz range data provided in the AVISO L2 products (, last access: 14 November 2018, and, last access: 14 November 2018). The resulting sea level time series are available every ∼0.29 and ∼0.19 km along the satellite tracks for Jason-2 and SARAL, respectively. However, we must keep in mind that if the use of high-rate altimeter measurements allows us to significantly improve the spatial resolution, the resulting SLAs are much noisier (see, for example, Birol and Delebecque, 2014). Considering the data availability (see below for the in situ observations), the study period chosen is 2010–2016 for all altimetry datasets.

The Jason-2 altimeter is designed as “conventional altimetry” as it operates in the Ku-band frequency. The SARAL altimeter operates in the Ka-band, allowing for a better performance in terms of spatial resolution (the radar footprint is smaller) and measurement noise. Morrow et al. (2017) analyzed the “mesoscale capability” (defined as the wavelength at which the noise is larger than the signal, which varies spatially as shown by Dufau et al., 2016) of these two altimeters in the NWMed using a statistical method (Xu and Fu, 2012). It allows us to have an estimate of the size of the structures that can be theoretically detected by each altimeter (on average) and to define the optimal data spatial filtering. Here, we did the same computation for each of the four tracks used in this study using all the data available, unlike in Morrow et al. (2017) in which the data located over the continental shelf were discarded. We obtained 49 km for the SARAL track 302, 39 km for the SARAL track 343, 34 km for the SARAL track 887 and 67 km for the Jason-2 track 222, which is coherent with the results of Morrow et al. (2017), who obtained 39 km for SARAL and 55 km for Jason-2 without the coastal altimetry observations. It suggests that the quality of nearshore altimetry SLA remains good. The lower values obtained for SARAL are due to the better signal-to-noise ratio of the AltiKa altimeter compared to Jason-2. The differences found among the three SARAL tracks are explained by their respective geographical locations. They capture different mesoscale features.

In order to have the best signal-to-noise ratio, we then filtered the data with a low-pass Loess filter using a cutoff frequency of 35 km for SARAL. Note that we have chosen a single value for the different SARAL tracks in order to have the same data processing and facilitate comparison between the different datasets. For Jason-2, we chose to use a processing as close as possible to the one of SARAL and then used a cutoff frequency of 40 km. The same low-pass filters were used for both 1 Hz and high-rate SLAs. One needs to keep in mind that noise remains in the filtered Jason-2 data.

Altimetry only provides sea level anomalies relative to a temporal mean. In order to estimate currents as close as possible to the currents measured or derived from the other instruments (see below), we added the regional mean dynamic topography (MDT) from Rio et al. (2014) to the altimetric SLA and computed the surface velocities (u) from the total sea level gradients observed between consecutive points along the track, assuming that the fluid is in geostrophic balance:

(1) u = - g f Δ SLA + MDT Δ x ,

where f is the Coriolis parameter, g the gravitational constant and Δx the distance between the points.

Only the across-track component of the geostrophic currents can be derived. The MDT product used is a regional product with a horizontal resolution of 1∕16 (i.e., lower than altimetry resolution in the along-track direction). Compared to other MDT products, it allows for a better representation of the NC in the Ligurian Sea (Rio et al., 2014).

2.2 In situ measurements

2.2.1 Glider data

Gliders have been deployed in the NWMed since 2005. However, it is only since 2009 that they have been regularly operating as part of the MOOSE network (, last access: 20 November 2018). In particular, on the Nice–Calvi line (Fig. 1, pink line), 36 deployments were undertaken between 2009 and 2016. Some of them have already been analyzed in different studies with different scientific objectives (Piterbarg et al., 2014, focused on frontal variability; Bosse et al., 2015, investigated sub-mesoscale anticyclones; Niewiadomska et al., 2008, analyzed physical–biogeochemical coupling mechanisms). Each glider deployment encompasses several transects, and the database includes 204 sections; 192 of them are between 2010 and 2016. The ones that are too short (<60 km) or moving too far away (>15 km) from an average trajectory computed from the individual ones were discarded. Finally, 173 glider transects along this line were used in this study. It represents a huge amount of observations and a large number of cases available for comparisons with altimetry or with other in situ observations.

Figure 1Study area and data distribution. Jason-2 and SARAL tracks are represented by the black and blue lines, respectively. The satellite tracks used in the study are indicated in bold. The region in orange corresponds to the HF radar coverage. The Nice–Calvi glider line is in purple and the TETHYS ADCP transect is in green. A map of the schematic regional circulation is presented in the upper left corner.


The campaigns were sliced into ascending (from Calvi to Nice) and descending (from Nice to Calvi) transects and the data were projected on a reference track. We assume that one dive or one ascent represents one vertical profile. In practice, data were discarded when the latitude was not monotonically varying or when the angular deviation between two consecutive points and the mean direction of the reference track was too strong (i.e., larger than 3 standard deviations (SDs) away from the mean angle). Then the data were gridded with a 4 km horizontal bin size along the reference track; 4 km corresponds to the average distance between two successive profiles.

During their mission, gliders measure temperature and salinity from the surface down to 1000 m (less if the bottom is shallower or if commanded to dive shallower). To avoid noise that is mainly due to aliased internal waves, temperature and salinity data have to be filtered. A Butterworth filter of second order (Durand et al., 2017) was applied. Different cutoff frequencies have been tested and we finally chose 15 km to avoid noise without removing small-scale variations (as in Bosse et al., 2017). From the temperature and salinity data we computed the density and then the geostrophic velocity component perpendicular to the reference track using the thermal wind equation. These velocities are referenced to 500 m, corresponding to the depth reached by all gliders. The difference with altimetry-derived currents is then that the barotropic component and the baroclinic component below 500 m are missing.

2.2.2 ADCP data

Since 1997, the TETHYS II RV has collected a large number of ADCP measurements during frequent repeat cruises between the French coast (Nice) and the DYFAMED–BOUSSOLE site (4325 N, 752 E). The corresponding ship transect is much shorter than the Nice–Calvi glider line (Fig. 1), but samples the NC at about the same location. From 1997 to 2014 a 150 kHz ADCP was used, with a vertical bin length of 4 m. In 2015, it was replaced by a 75 kHz ADCP, providing data with 8 m vertical resolution. The first valid measurement is located at 8 and 18 m of depth for the first and second ADCP. Processed and validated data were obtained from the DT-INSU data center (, last access: 20 November 2018). A total of 513 vertical sections of horizontal currents in earth geographical coordinates are provided from November 1997 to March 2017. This number is reduced to 218 during the period 2010–2016. We only used the ADCP transects with a very precise heading, which leaves us with 151 sections. Following the same strategy as for glider data, the data were gridded with a 2 km horizontal bin size along a reference transect going from the French coast to the DYFAMED site (green line in Fig. 1). Ship tracks located outside the chosen grid bins, incomplete transects and data associated with a ship direction that deviates too much from the reference trajectory (generally corresponding to ship stations) were eliminated. For each cruise, we have one return trip, sometimes two. After a visual inspection of each individual transect to check the coherence of the currents measured during the same day, the data have been averaged per bin to have one daily-averaged transect. It finally leads to a total of 134 selected current sections. In this study, we focused on the 34 m depth cell in order to strongly reduce the surface instrumental errors.

2.2.3 HF radars

The HF radar data used here (orange zone in Fig. 1) are also part of the MOOSE network (Zakardjian and Quentin, 2018). They target the area off the coast of Toulon as a key zone conditioning the behavior of the NC just upstream of the Gulf of Lions. Due to a sharp bathymetry and several islands that deflect the NC southwestward, significant mesoscale variability and cross-shelf exchanges exist in this area (Guihou et al., 2013), correlated with strong northwesterly winds (Mistral, Tramontane). The system consists of two HF (16 MHz) Wellen radar (WERA) instruments installed near Toulon in monostatic (Cap Sicié station) and bistatic (Cap Bénat–Porquerolles island stations) eight-antenna configurations (see Quentin et al., 2013, 2014, for details). They work with a 50 kHz bandwidth, resulting in a 3 km range resolution, a direction-finding method based on MUSIC (multiple-signal classification algorithm; see Lipa et al., 2006; Molcard et al., 2009) allowing for a 2 azimuthal resolution and a time integration of 20 min. The radial velocity maps are averaged over a 1 h time window and Cartesian total velocities are then reconstructed on a regular 2×2 km grid. More details on this HF radar site can be found in Sentchev et al. (2017), who found an overall good agreement between derived radial velocities and in situ ADCP, with relative errors of 1 and 9 % and root mean square (RMS) differences of 0.02 and 0.04 m s−1; this is slightly increased in velocity and direction for the reconstructed total velocities, but mainly in conditions of nonstationary wind forcing. The MOOSE HF radar database used here is made up of daily (one diurnal lunar period of 25 h) averaged surface currents computed from the reprocessed hourly total velocity data (QC level L3B, i.e., velocity threshold and geometric dilution of precision – GDOP – tests passed) with additional cleaning of residual RFI (radio frequency interference) outliers using an outlier removal algorithm based on the number of L3B valid data, variance and mean over an inertial period window (17 h at 43 N). The data are then filtered from tides and inertial oscillations. The time series starts in May 2012 and ends in September 2014 with a total of 732 days of available data. The size of the area covered by total velocities after the GDOP test is roughly 60×40 km and it is located about 170 km westward of the glider and ADCP observations.

Figure 2(a) Map of the mean current values derived from ADCP, glider, HF radar and altimetry data over the period March 2013–October 2014. (b) Zoomed-in view of the northern Ligurian Sea (black rectangle indicated in panel a); 200 m (red line) and 1000 m (black line) isobaths are also shown. Current values are positive (negative) to the right (left) of the ship, glider or satellite tracks.


2.3 Differences between the currents derived from the different observational techniques

In this study, we extensively compare the currents derived from the four different techniques described above with the objective of better understanding how they can optimally complement each other for the observation and study of variability in the NC circulation system. However, we must first have in mind the intrinsic characteristics of each type of current observation and the differences between the datasets.

2.3.1 Spatial and temporal sampling

First, the locations of the different types of observations do not coincide with each other, and their temporal and spatial sampling is also very different. After processing, current values are obtained every 2 km along the ship ADCP track, every 4 km along the glider line, in a 3 km resolution grid for the HF radar, every 5–6 to 7–8 km along the satellite track for 1 Hz Jason-2–SARAL altimetry and every 0.29 to 0.19 km for HF Jason-2–SARAL altimetry. Moreover, each instrument is characterized by specific measurement errors and a specific signal-to-noise ratio. Filtering has to be applied on the glider and altimetry data, still limiting the wavelengths of the current that can be resolved (see above and in Table 1). We also have to keep in mind instrumental limitations concerning the area that can be monitored. The ship ADCPs, the HF radars and the gliders have a higher spatial resolution than the filtered altimetry data but a much more limited spatial coverage. We also have to consider the fact that access to altimetry data, at least in the standard 1 Hz version, still remains limited in the 10–15 km coastal band. As the NC fluctuates in both location and width and at both seasonal and much higher frequencies (Albérola et al., 1995), it can make a large difference in the ability of the instrument considered to capture this current flowing along the continental slope, often located very close to the coastline (Fig. 2).

Table 1Main characteristics of the different current datasets used in this study.

Download Print Version | Download XLSX

Table 2Number of data samples per month for each current dataset during the period 1 January 2010–31 December 2016. The number of data selected for the climatology computation is indicated in brackets.

Download Print Version | Download XLSX

Concerning the temporal sampling, the HF radars and the altimetry provide current observations at regular intervals: every day for the HF radar product used here, every 10 days for Jason-2 and every 35 days for SARAL. The glider and ADCP data are available between zero and nine times per month and between zero and five times per month, respectively. These unevenly spaced time series make the corresponding data analysis more complex since it can produce significant biases in the distribution of the NC properties (for example, its seasonal variations; see Table 2). It will also be influenced by the period of observations available: from about 2 years for the HF radar to more than 6 years for the ADCP, glider and Jason-2 data (see Table 1).

2.3.2 Vertical sampling

The depth of the current measurement also varies for the different instruments: HF radars and altimeters observe the ocean surface and subsurface, while ADCPs and gliders provide vertical sections of measurements. Using both glider and ADCP data, we compared the currents computed at different depths (18, 34 and 50 m) and did not find significant differences: less than 5 cm s−1 for the mean NC core velocity and around 2–3 cm s−1 for the corresponding SD value. We then decided to use the glider data at 34 m of depth to be coherent with the ADCP observations. We do not consider this to be a significant source of differences with altimetry currents in representing near-surface currents.

2.3.3 Physical content

Moreover, the different instruments do not capture the same physical content. The ADCP and the HF radars measure total instantaneous velocities, while the gliders and altimeters allow us to derive only the geostrophic current component perpendicular to the satellite or glider track (i.e., excluding the ageostrophic parts, such as wind-driven surface current, tidal currents and internal waves, and the current component parallel to the track). Unlike the other current data sources used here, altimetry gives only access to current anomalies. But the addition of a synthetic MDT allows us to overcome this difficulty if its quality is good enough to derive a reliable mean velocity field. After the addition of the MDT, the gliders and altimeters are clearly the closest in terms of current information derived. However, the glider currents are computed from hydrographic measurement profiles with a reference level of 500 m. They miss the barotropic and the deeper baroclinic geostrophic current components, while altimetry and MDT allow us to estimate absolute geostrophic currents representative of the horizontal density gradients integrated over the whole water column. In this study, in order to minimize the differences between the current datasets, we performed a projection of the ADCP velocities to obtain the current component perpendicular to the ship transects. Concerning the gliders, estimates of depth-averaged currents computed following the Testor et al. (2018) approach were added to the velocity data as an estimation of the barotropic component.

All the differences mentioned above are summarized in Table 1. If the data appear complementary in terms of space–time coverage and resolution, we can anticipate that their respective characteristics make their comparison and combination an issue. This will be analyzed in detail in Sect. 3.

3 Results

The results below are obtained from 1 Hz standard altimetry measurements, except in Sect. 3.4, which is dedicated to the analysis of the potential of 20 and 40 Hz altimetry data for coastal circulation studies.

3.1 Mean flow and spatial variability: a regional view

From Fig. 1, we can expect that the different observations mentioned above allow us to efficiently detect different characteristics of the NC (intensity, position) along its axis and the variability of these characteristics. In order to have a first general view of how the different velocity fields compare, we have computed their time average and their standard deviation values at each point of observation for a common period of time: from March 2013 to October 2014. We need to keep in mind that it corresponds to very different sample sizes: 33 ADCP sections, eight glider transects, 484 days of HF radar measurements, and 54–56 and 16 current data points for Jason-2 and SARAL satellite altimetry, respectively. Glider–HF radar observations will then have the lowest–highest significance in terms of statistics. Concerning the HF radars, only the zonal current component is taken into account. Note, however, that in this area, since the NC is almost zonal, most of its mean and variability are captured in the corresponding statistics. Figure 2 shows the resulting map of the mean current and its standard deviation is in Fig. 3. Here, we choose not to represent the results for all the SARAL tracks in order to avoid overloading the figures. Both the regional map (Figs. 2a and 3a) and a zoomed-in view of the northern Ligurian Sea (Figs. 2b and 3b), where the largest number of current observations are located, are shown.

From Fig. 1 (see the circulation scheme), we expect negative–positive current values along the northern–southern branch of the cyclonic NC system. It corresponds to what is observed in Fig. 2, in which one can notice a very good consistency of the mean currents derived from all the different instruments. Putting together all the pieces of information, the regional structure of the circulation emerges. As already shown in Birol et al. (2010), in the Tyrrhenian Sea, the northwestward Tyrrhenian Current (TC) is well observed at the northern end of Jason-2 track 161. Further north, the NC is formed by the merging of the Eastern Corsica Current (ECC), captured just east of Corsica by the Jason-2 track 085, and the Western Corsica Current (WCC), well captured by both the gliders and the SARAL track 343. The WCC, however, appears more extended towards the open sea in the SARAL data compared to the glider. The NC is then strongly constrained by the bathymetry and follows the continental slope along the coasts of Italy, France and Spain. It can be continuously followed from the SARAL track 343 to the Jason-2 track 070, through the ADCP, glider and HF radar observations. Mean NC velocities larger than −0.3 m s−1 are observed in the Ligurian Sea by ADCPs and Jason-2 altimetry, as well as off Toulon by the HF radars. Then the continental slope current slows down offshore of the Gulf of Lions: the Jason-2 track 146 gives a mean current value of -0.15 m s−1. Its flow is then almost divided into three in the Balearic Sea (-0.10 m s−1). Further south, around 40.5 N, 5–6 E and between 42 and 42.5 N, 7–8 E, an eastward flow, probably associated with the Balearic Front, which closes the cyclonic circulation south of the northwestern Mediterranean Basin, is captured by Jason-2 tracks 146, 009 and 222, as well as SARAL tracks 302 and 887, from west to east. Around 8 E, it slightly deviates to the southeast before joining the WCC.

If we focus on the northern Ligurian Sea (Fig. 2b), the cross-track direction of Jason-2 track 009 is not well oriented compared to the local axis of the NC. In this area, the continental shelf is very narrow and as a consequence the NC is very close to the coast: altimetry struggles to observe the corresponding flow. However, the Jason-2 track 009 and SARAL track 887 still capture a westward current at their northern end. Considering altimetry, Jason-2 track 222, located further southwestward, appears better oriented to monitor the NC. In this area, despite the difference in the number of data samples, the altimetry, ADCP and glider mean current values are very close: between −0.24 and −0.32 m s−1 for all of them. The width of the NC tends to vary from one instrument to another. With the gliders it appears slightly narrower than with the ADCP and altimetry (i.e., SARAL track 887). Note also that the ADCPs and gliders, which provide more nearshore information, show a positive or almost null flow very close to the coast that is not observed by altimetry, which stops further offshore. Still further west, the altimetry and HF radars also capture a coherent mean NC flow, but with larger values in HF radars (-0.44 m s−1) than in altimetry (-0.28 m s−1). This difference is probably due to the ageostrophic motions captured by the HF radars, but not by altimetry, and to the differences in the data resolution.

Figure 3(a) Map of the standard deviations of the velocities derived from ADCP, glider, HF radar and altimetry data over the period March 2013–October 2014. (b) Zoom-in view of the northern Ligurian Sea (black rectangle indicated in panel a); 200 m (red line) and 1000 m (black line) isobaths are also shown.


Figure 4Time–space diagrams of the current velocities derived from (a) SARAL track 887, (b) ADCP, (c) gliders, (d) Jason-2 track 222, (e) SARAL track 302, and (f) HF radars between March 2013 and October 2014. The pink and grey areas in the background of the diagrams correspond to the summer and winter seasons, respectively.


Figure 3 represents the associated current variability, as captured by the different types of observations. Not surprisingly, in all datasets, larger standard deviation values generally coincide with the NC system. In altimetry, we observe values of 0.12–0.2 m s−1 at the northern ends of the Jason-2 tracks 161, 085, 044, 222, 146 and 070 (the signal at the end of track 146 does not correspond to the NC) and SARAL tracks 302, 343 and 887. If we focus on Jason-2 track 222 in Fig. 3b, we first clearly see the coastal current variations associated with the NC flow (see also Fig. 2b). However, the NC is not fully resolved by 1 Hz altimetry data: observations stop at ∼10 km from land. The more coastal observations have been discarded during the processing, probably due to large data errors. This is even more true for the Jason-2 track 009 (the last data point available is associated with a large suspicious current value) and the SARAL tracks 887 and 302. We have to keep in mind that in this area, where the narrow NC flow is very close to the coastline (its core is in the range 10–40 km from land; Piterbarg et al., 2014), its observation by altimetry is very challenging. In comparison, the ADCP, glider and HF radar data allow us to observe the NC variability much closer to the coast: our datasets stop at 2.5, 3.5 and 3–7 km from land, respectively. But they all differ in the current variance captured. Concerning the ADCPs and gliders observing the NC at the same location, the ADCPs show larger standard deviation values (∼0.13 m s−1) almost all along the transect, while the gliders show much lower values in the open ocean (∼0.05 m s−1), increasing on the shelf break to values very close to the ones observed on Jason-2 track 222 (∼0.15–0.20 m s−1). Further west, the HF radars show the largest current variance south of Toulon, with values around 0.23 m s−1, located on the continental shelf break. In comparison, the corresponding NC variance captured by the SARAL track 302 is only half of that. Further south, off Corsica, the gliders show very low variability, roughly half of the values corresponding to the NC, indicating a WCC flow that is very stable in time (as also shown in Astraldi and Gasparini, 1992).

Considering the intrinsic and important differences between the different current datasets (Sect. 2.3), these first statistical results are encouraging. They give a coherent picture of the regional circulation, with, except for the HF radars that capture a faster current flow, about the same NC average velocity values. The NC variability is also clearly captured by the different datasets all along its path, but with significant differences in terms of amplitude. Note that when we recompute the standard deviations using a larger period of time (not shown), ADCPs and gliders tend to converge toward the same cross-shore profile as the one derived from Jason-2 track 222, with a maximum about 0.03 m s−1 larger for the in situ observations. We can then conclude that this diagnostic is largely influenced by the number of data samples considered as well as by the period of time covered by the measurements.

In order to better understand the differences in variability captured by the various datasets, we analyze the time–space diagrams of the currents derived from ADCP, HF radar, glider and altimetry data over the period considered (Fig. 4). We focus on the first 60 km off the French coast and, concerning altimetry, on SARAL tracks 302 and 887 and on Jason-2 track 222. The HF radar data correspond to a meridional section of the zonal current component located at 6.2 E. The NC is clearly detected in all data but Fig. 4 displays large variations at different timescales (see also Font et al., 1995; Sammari et al., 1995; Albérola et al., 1995) that make the data temporal sampling resolution a very sensitive question if we want to study this current system. The number of glider transects is low and concentrated in 2013, and the unevenly spaced ADCP sections miss a large number of events. Spring 2013 and winter and summer 2014 are poorly sampled. The HF radar provides a very good temporal sampling according to what is needed to capture the high-frequency NC variations, but it monitors only its section located in the vicinity of Toulon. Altimetry provides good complementary information. Despite its relatively low spatial resolution and the intrinsic difficulties when approaching the land, it detects seasonal changes coherent with the ones observed in the other datasets as well as much shorter period changes. Note that if the SARAL mission capabilities are expected to be particularly adapted for fine-scale oceanography and coastal applications (Verron et al., 2018), in our case study its 35-day period appears to be a strong limitation on monitoring the highly fluctuating NC flow. This particular point will be further analyzed in Sect. 3.3. In the next section, we concentrate on the seasonal variability observed in the different datasets, as it is known to be the dominant signal of the NC system at regional scale (Alberola et al., 1995; Sammari et al., 1995; Crépon et al., 1982; Birol et al., 2010).

3.2 The seasonal variability of the NC flow captured by the different instruments

Here we compare the monthly climatology (i.e., the mean value for each month of the year) of the maximum NC amplitude computed from the different current datasets (ADCP, glider, HF radar and altimetry). This time, we use all the data available during the period 1 January 2010–31 December 2016 (note that the HF radar data are only available over the period 2012–2014). Concerning altimetry, we consider only Jason-2 since we have two to four samples per month for SARAL, which is not enough to compute meaningful statistics (see Table 2). For each data sample available, the current profiles along the Jason-2 track 222, the ADCP and glider reference transects, and a meridional HF radar section located at 6.2 E are analyzed. The maximum NC amplitude is defined as the average of the first decile of the velocity values for each transect and time (remember that the NC corresponds to negative current values). These values must be close in space. This strategy allows us to filter large isolated current values, which may not correspond to the NC. In altimetry, only a distance spanning 60 km to the coast is considered. The number of data points in the first decile varies according to the dataset and to the number of data in the section considered. Because of the lower resolution, it always corresponds to one point in altimetry. As we can see in Fig. 4d, data gaps exist in Jason-2 for some cycles. When more than three points are missing, the corresponding cycle is discarded from the analysis. Finally, all the maximum NC values collected are averaged as a function of month and dataset, and they are synthesized in monthly climatologies. The results derived from in situ data are in Fig. 5a and the results derived from altimetry are in Fig. 5b. The glider results are in both figures because this instrument provides the currents closest to altimetry in terms of physical content. For each month, the standard deviation computed from all the NC amplitude values available is also indicated.

Table 2 lists the temporal distribution of the number of samples included in the calculation as a function of month (in brackets). The data density is much more important than in Sect. 3.1 and the corresponding statistics more robust. It appears relatively stable for Jason-2 altimetry and more heterogeneous for the other observations. The number of in situ data points per month is strongly variable, especially for the ADCP and to a lesser extent for the glider, and varies also a lot from one year to another. A total of 24 ADCP transects are available in 2015 and only 7 in 2012 and 2014, while the glider dataset has a large gap in 2014. As a consequence, the results will only be discussed in terms of seasonal tendencies.

Figure 5Seasonal variations of the maximum current amplitude derived from the (a) HF radars (green line), ADCP (red line), gliders (blue line), and (b) Jason-2 (black line) and glider (blue line) observations available over the period 1 January 2010–31 December 2016. (c) Same as (a) and (b) but computed over the period July 2008 to June 2014 and only for the gliders, ADCP and Jason-2. For all the curves the monthly standard deviation of the maximum current amplitude derived from the corresponding instrument is also indicated (curve envelopes and error bars).


In Fig. 5a and b, except altimetry, all the climatologies show a clear and coherent seasonal cycle of the NC amplitude, with a stronger–lower flow in winter–summer. As already seen in the previous section, compared to the other datasets, the HF radars capture a faster NC south of Toulon. Higher NC velocities are expected in this location (Ourmières et al., 2011). The corresponding amplitude of the seasonal variations is 0.32 m s−1, with a minimum of −0.34 m s−1 in August and a maximum of −0.66 m s−1 in February. These values are also found by Guihou et al. (2013) in the same area. In comparison, further east in the northern Ligurian Sea, the peak-to-peak amplitude of the seasonal cycle is slightly lower for the ADCPs than for the HF radars and is associated with a lower mean flow, with a minimum of -0.27 m s−1 in August and a maximum of −0.54 m s−1 in January. Note, however, that the value observed in January may be less robust (or at least poorly representative of a mean monthly situation) since it is computed only with three data samples. Concerning the gliders, the peak-to-peak amplitude variation is ∼25 % lower than for the ADCPs, with a minimum of -0.25 m s−1 in August–September and a maximum of −0.46 m s−1 in December. Since these instruments measure velocities at very close locations, the differences may be mainly due to ageostrophic currents. The Jason-2 climatology displays significantly different results with a series of maxima (-0.46 m s−1 in February and November) and minima (-0.35 m s−1 in May and October).

Table 3List of the cases of relative co-localization in time between the glider, ADCP and altimetry current data, with the corresponding dates of observations.

Download Print Version | Download XLSX

Figure 6Cross-shore sections of currents deduced from the glider (blue), ADCP (red), SARAL (green) and J2 (black) altimetry data for the seven individual cases identified in Table 3. Overlapping periods between the different observations are also indicated.


For further analysis, we consider the dispersion of individual current values for each month (Fig. 5a, b, envelopes around the curves). We observe significantly different date-to-date variability for each month: between 0.03 and 0.15 m s−1 for the glider and ADCP, between 0.12 and 0.20 m s−1 for the HF radar, and between 0.08 and 0.17 m s−1 for altimetry. It indicates that the seasonal NC cycle observed in Fig. 5 is modulated by a strong mesoscale and/or year-to-year variability, and it seems to be especially true during intermediate seasons. The dispersion curve of Jason-2 generally follows the other ones except in July and September, when it shows large peaks of variability. Deeper inspection of the corresponding current dataset reveals that it is due to much larger NC amplitudes observed during these months in 2014 and 2015. The corresponding NC intensifications are clearly observed in Fig. 4d in July and September 2014. Unfortunately, no glider transect is available during these periods (Fig. 4c) and we have only one ADCP section, which does not show an NC flow increase (Fig. 4b). However, the HF radar currents (Fig. 4f) tend to support the fact that the NC intensification captured by Jason-2 is realistic and not due to altimetry errors. One profile of SARAL track 887 is available in July 2014 and it exhibits the same feature (Fig. 4a). Since we did not find evidence of summer NC intensification in previous years, we decided to recompute the seasonal cycle of the NC amplitude using only the data available during the first 6-year period of Jason-2 (i.e., 2008–2014). We did the same for the ADCPs and gliders, but very few glider data and no ADCP currents are available before 2010. HF radar currents have not been considered because of the too-short length of the time series. The resulting curves are shown in Figure 5c and a clear seasonal cycle is now also observed in the climatology derived from Jason-2, with a summer–winter decrease–increase in the NC flow. Note that it is also coherent with the results of Birol et al. (2010), who used a combination of the T/P and Jason-1 altimeter missions to obtain a current time series over the 1993–2007 time period. The amplitudes of the seasonal variations computed during this new period of time are now around 0.29, 0.27 and 0.16 m s−1 for the ADCP, glider and Jason-2 altimetry data, respectively. Figure 5c highlights the fact that the summer velocities measured by in situ instruments are relatively close on average. During winter and especially spring, the differences become significant in both amplitude and phase.

Two physical processes can explain the fact that the differences between the different types of current measurements vary as a function of season. First, the stronger mesoscale variability associated with the NC during winter and spring makes the space and time sampling of the current measurements a more critical issue for the study of this current system at that particular time of year. Second, the strong Tramontane and Mistral winds are more frequent in winter and spring. Then, the differences between the glider and the ADCP current measurements, very close in location, may be more important when the non-geostrophic dynamics (in particular the Ekman flow) produced by the strong winds are more important. The closest seasonal variations to the ones observed by altimetry are found for the glider. It is not surprising since the currents derived from this instrument are also the closest in terms of physical content (see Sect. 2.3). Despite the spatial resolution of the altimetry data and the width and very coastal location of the NC, the amplitude of its seasonal variations captured by the Jason-2 track 222 along the French coast is 55 %–60 % of the amplitude captured by both the gliders and ADCPs.

3.3 Individual snapshots

To learn more about the similarities and differences between the currents derived from the different instruments, as well as their causes, we now analyze the observations on particular dates. In order to minimize, as far as possible, the differences due to distances in space and time between observations, we focus here on the region near Nice (i.e., on the ADCP and glider data, as well as on SARAL track 887 and Jason-2 track 222) and consider only observations that are close in time. For each day of the 2010–2016 study period, we used a time window for each dataset: 5 days for Jason-2, 10 days for the glider and ADCP data, and 22 days for SARAL. We selected only the dates for which the four types of observations are available and finally obtained seven cases that are reported in Table 3. The corresponding cross-track currents are shown in Fig. 6 (by season) as a function of the distance to the point at which the corresponding transect intersects the coastline. For each case and each dataset, we have computed the maximum NC amplitude, following the same method as in Sect. 3.2, and the corresponding location. The latter is expressed in terms of distance to the coast. The results are provided in Table 4.

Figure 6 highlights very different NC situations. Here, the largest coastal current velocities are observed in spring and not in winter as expected from Sect. 3.2. Case 1 (Fig. 6a), the only one in this season, shows by far the strongest NC amplitudes in ADCP and glider data (<-0.6 m s−1) associated with a narrow flow located within the 30 km coastal band. It corresponds to a difficult study case for altimetry, which is still able to depict the NC, but with a too-large current vein with an amplitude less than half of what is observed in the in situ observations. Cases 2 and 4 (Fig. 6b, c) are in summer. The NC is broader and its velocity is around −0.3 m s−1 in all datasets, except in the glider of case 4 (see below). This time, altimetry successfully captures the NC amplitude; the location of its core is also good in case 4 but not in case 2 (it is too far to the coast for SARAL). In case 4, altimetry and ADCP currents are very close but, for a reason that is unclear (it may be due to an NC meander or eddy captured by the glider and not by the other instruments), the glider represents a significant slower flow located further south. Cases 5 and 6 (Fig. 6d, e) both correspond to autumn situations but they highlight very different coastal current patterns. In case 5, the glider and SARAL data corresponding to the same day are very coherent: they show a relatively weak NC flow (-0.2 m s−1) with a core ∼30 km to the coast. Jason-2 observations, very close in time to SARAL and the glider data, show a larger current located slightly further south (∼6 km). The ADCP represents an NC vein at the same location as the glider and SARAL but with a much stronger amplitude. It could be due to the differences in the dates of observations (1 week from Table 3, the temporal scale at which meanders develop) or an important ageostrophic NC component. In case 6, a lack of data for Jason-2 can be observed, which leads us to question the realism of the current estimates close to the coast. However, the glider, the ADCP and SARAL data show a broad NC located further offshore than in the other cases. Its core is located ∼40 km offshore in ADCP and glider data. As in case 5, the glider and SARAL data provide NC amplitudes and locations that are relatively close and the ADCP data give a larger NC maximum. A particular feature in this autumn situation is the succession of very strong and narrow southwestward and then northeastward flows observed in the first 20 km of the coastal band in both ADCP and glider currents. It is not captured by SARAL, which does not get close enough to the coast. It is probably associated with an eddy or meander stuck on the northern anticyclonic side of the NC (eddies were documented at this location in Casella et al., 2011). Finally, cases 3 and 7 (Fig. 6g, f) correspond to winter situations and, as for the autumn, they are very different. In case 3, we observe a broad NC with a core located around 30 km to the coast. The glider exhibits current oscillations along its transect but all current datasets show a coherent representation of the NC, even if the ADCP data provide larger velocities. In case 7, the glider and ADCP capture a narrow NC located ∼20 km off the coast also observed by altimetry but with some differences: in Jason-2 the NC flow is not entirely captured and in SARAL it is located further offshore. It may be due to rapid variations in the NC between the different dates of observations: 12 days between ADCP and SARAL.

Beyond the large variations in the NC characteristics from one case to another, an interesting feature in Fig. 6 is the presence of an eastward flow located south of the NC (i.e., 100–150 km to the coast) in altimetry data in different cases (cases 4, 5 and 6 in particular). The ADCP transect is too short to capture this current vein and it is not observed in the glider data, located further east compared to SARAL track 887 and Jason-2 track 222. The latter rather depict the WCC on the southern edge of its section. To our knowledge, this offshore eastward flow is not documented in the literature but its signature also seems to be observed in Figs. 2a and 3a (around 42.5 N in SARAL and around 42.8 N in Jason-2). It will be further discussed in Sect. 3.5.

Finally, what is illustrated in Fig. 6 is that, because of the large short-term changes in the NC circulation system, each snapshot of observations differs significantly from the corresponding seasonal average. It highlights the strong interest in long-term and regular altimetry data to study the persistent components of the NC circulation system, as well as its seasonal variations and possible longer-term changes.

Figure 7Same as Fig. 6 but for HF altimetry data.


3.4 Can we improve the estimation of the NC characteristics with high-rate altimetry compared to 1 Hz data?

In this section we consider the improvement that is possible to obtain in terms of current derivation with the use of high-rate altimetry measurements, compared to the conventional 1 Hz data used above. However, if research coastal altimetry products that are calibrated, validated, and cover different regions and missions are now available at 1 Hz, this is not the case for high-rate altimetry products. Even if some studies have shown the better performance of 20 and 40 Hz altimeter measurements in observing coastal circulation (Birol and Delebecque, 2014; Gomez-Enri et al., 2016), they are much noisier and there is no consensus yet concerning their (post-)processing. Here, we used an experimental version of high-rate X-TRACK SLA data for both Jason-2 and SARAL, for which original measurements are at 20 and 40 Hz, respectively. Since a lot of erroneous data remained in the coastal area, we applied a 2-sigma filter on the resulting SLA fields along each individual track and cycle in order to edit the data before filtering and the computation of the current estimates (Sect. 2.1).

In order to analyze if we can expect a better observation and understanding of NC variations from high-rate altimetry measurements, they have been used to compute the same diagnostics as in Sect. 3.1, 3.2 and 3.3. Only the results for the individual snapshots will be illustrated here (Fig. 7) since, even if the major difference with the current fields derived from 1 Hz altimetry is that the larger number of coastal data points allows us to estimate currents closer to the coast and then to better resolve the NC flow (see Fig. 7), we did not find significant differences in the NC statistics (i.e., mean current and standard deviation values) or the amplitude of the seasonal cycle computed from 20 and 40 Hz SLA compared to the 1 Hz solutions.

Table 4Maximum NC value and distance to the coast of this maximum deduced from the glider, ADCP and altimetry current data for the seven individual cases listed in Table 3.

Download Print Version | Download XLSX

In Fig. 7, the same color code as in Fig. 6 is used. For each case, as in Sect. 3.3, the maximum NC amplitude and corresponding location are reported in Table 4 for both SARAL and Jason-2. In case 1 (Fig. 7a), the gain obtained with the use of HF data is very clear. On this date the NC vein is narrow and located near the coast. Contrary to the 1 Hz solution, the NC is better resolved by both SARAL and Jason-2 high-rate altimetry. It is especially true for SARAL with NC characteristics that are almost identical to the ones derived from the gliders. In Jason-2, the NC core is also close to the glider solution but its amplitude is ∼35 % lower. For cases 2 and 4, which correspond to the summer (Fig. 7b and c), here again the use of high-rate altimetry allows for the better observation of an NC vein but the agreement with in situ data is not so good. Concerning SARAL, for case 2, the current estimates are suspect since a reduction of the current intensity appears at the location of the NC core in the other datasets (Fig. 7b). For case 4, SARAL NC amplitude is too high: 0.55 m s−1 vs. 0.16 m s−1 for the glider. Jason-2 high-rate NC estimates appear closer to the in situ data than SARAL for both cases 2 and 4, but the resulting NC characteristics do not appear better than the corresponding 1 Hz estimations when compared to ADCP (Table 4). It probably reveals that the cutoff frequency chosen in the filtering is too low. Cases 5 and 6 (Fig. 7d and e) also show some very doubtful oscillations in both SARAL and Jason-2 currents, and high-rate altimetry does not improve the NC estimations. In winter, the cases 3 and 7 (Fig. 7g and f, respectively) are very different. In case 7, 20 Hz Jason-2 data depict the entire NC with current estimates much closer to in situ data (especially the glider) compared to 1 Hz Jason-2 measurements. In case 7 they degrade–improve the NC representation (Fig. 7g) if we refer to the glider–ADCP, respectively. Note that this case illustrates the difficulty of the calibration of altimetry data processing algorithms with independent observations since results may differ as a function of the independent observations used. Here, 40 Hz SARAL data show a too-noisy current solution.

As already shown in previous work (Birol and Delebecque, 2014; Gomez-Enri et al., 2016), high-rate altimetry allows us to derive significantly more sea level data near the coast. Here we observe that the coastal circulation derived is better resolved in space, both in terms of horizontal resolution and distance to the coast of the current estimates. However, the resulting current fields depend crucially on the strategy followed for data processing, including retracking, corrections, screening and filtering.

Figure 8Seasonal climatology maps of cross-track geostrophic currents (in m s−1) derived from Jason-2 and SARAL/AltiKa altimeter data over the period April 2013–April 2016.


3.5 The seasonal variability of the regional surface circulation observed by altimetry

Here we use only 1 Hz altimetry data. In order to separate the seasonal component of the surface circulation from the mesoscale variations, along each pass of Jason-2 and SARAL located in the area of interest, we have computed a seasonal “climatology” of the cross-track surface geostrophic currents captured by these two altimetry missions (Fig. 8). It was done by simply averaging the corresponding seasonal velocity values for the common 3-year period: April 2013–April 2016. Note that this type of analysis can also be found in Birol et al. (2010) with a much longer period of altimetry data, but with Jason measurements only. The need to use multi-mission observations was incidentally pointed out in this study. Here, indeed, the combination with SARAL data largely improves the spatial resolution of the regional circulation, enabling us to capture the main current veins at many more locations along their path (see Fig. 9 of Birol et al., 2010, for comparison).

In Fig. 8, all the structures of the standard circulation scheme in the NW Mediterranean Sea (Fig. 1) are observed: the NC, the WCC, the Balearic Current, the Balearic Front and the TC. What can also be noticed first is the very good coherence and complementarity between the SARAL and Jason-2 climatologies, especially at crossover points. The seasonal variations in the regional circulation system, already discussed in detail in Birol et al. (2010), are confirmed from this different and shorter period of altimetry observations. In particular, if a stronger and unique southwestward flow is observed along the Italian, French and Spanish coasts from autumn to spring, it is not so clear during summer. During this season, the NC does not seem to continue west of 4 E to reach the Balearic Sea. Instead, it may recirculate eastward offshore of Cape Creus.

More generally, compared to Birol et al. (2010), the better spatial coverage obtained by combining both SARAL and Jason-2 reveals a circulation scheme that could be much more complex than the one classically proposed in the literature. In summer and autumn (Fig. 8a, d), between 3 and 9 E, individual eastward current veins are observed between the NC and the Balearic Front, suggesting that recirculations may exist along its path during these seasons. One of them corresponds to the eastward current branch mentioned in Sect. 3.3. Note, however, that this seasonal analysis is based only on 3 years of observations and could be biased by particular features occurring during 2015. Further investigation based on numerical modeling is clearly needed. This is the next step of this study. Here again, altimetry clearly appears to be a very good tool to validate the model results.

4 Discussion and conclusion

The characteristics of the dynamics, as well as the diverse arrays of in situ instrumentation in the NWMed, offer the possibility to evaluate in detail the complementarity between different types of measurements to monitor coastal ocean circulation. In this study, a systematic comparison of current data derived from different platforms provides new insights into the biases that their differences cause in estimations of NC characteristics. Compared to previous studies comparing altimetry and in situ observations, the originality of this study comes from the number of instruments and observations used, as well as from the long time period addressed and the area covered. It demonstrates that altimetry can be integrated into multi-platform coastal current monitoring systems and enables us to analyze the relative capability of each type of instrument.

The HF radars provide a good daily view of the NC but only for a small area (60×40 km) and, as they observe only the surface layer, the NC can be hidden by a strong Ekman flow. The ship-mounted ADCP allows us to see the vertical NC structure at very high resolution and up to the coast, but it is irregularly sampled and the measurements may contain unsteady ageostrophic current components such as inertial oscillations (Petrenko et al., 2008). Since they can be operated on a routine basis only in a few places, we have only one regular section crossing the NC off the French coast and it is relatively short. It is also the case for gliders with horizontal resolution and temporal sampling lower than that of the ADCP and the HF radars but that provide much longer sections of observations. More generally, they also allow us to measure a large number of physical and biological ocean parameters. Along-track altimetry provides reasonably good monitoring of surface currents in both space and time but its effective spatial resolution (Sect. 2.1) does not allow us to resolve all the mesoscale and sub-mesoscale signals associated with the NC. Here, the combination of all the observations derived from the different instruments highlights the continuity of the NC from the Italian coast up to the Spanish coast. The general coherency between the different current estimations also enables us to go one step forward in the quantification of the NC components that can be observed in altimetry.

If we consider a reasonably long time series of observations including enough data samples for each instrument (see Sect. 3.2), in the northern Ligurian Sea, the average NC value derived from altimetry is −0.3 m s−1 and is coherent with the estimations derived from the other instruments. Concerning the amplitude of its seasonal variations, it is underestimated by ∼40–45 % on average compared to both the glider (the closest instrument in terms of the physical content of current estimations) and the ADCP (the highest-resolution current dataset). Altimetry-derived currents will miss a larger part of the absolute surface velocity field in winter and spring compared to summer and autumn because the Ekman component and finer-scale motions are more important during those seasons. For individual dates, the NC component that is not observed by altimetry varies a lot from a correct NC amplitude estimation to no NC observation as a function of the location (i.e., more or less close to the coast) and width of the NC.

This study also enables us to compare the relative performance of two generations of altimetry missions and of both 1 Hz and high-rate measurements. It confirms that the standard 1 Hz along-track altimetry products derived from Ku-band radars provide meaningful estimations of the NC (as already shown in Birol et al., 2010, and Birol and Delebecque, 2014). The new Ka-band SARAL altimeter data tend to give estimations of the NC characteristics that are closer to in situ data in a number of cases but its 35-day cycle is clearly a strong limitation for the study of this coastal current system. The use of 20 and 40 Hz altimetry measurements significantly improves the number of near-coastal sea level data points and the resolution of the NC. However, the currents derived are still relatively noisy, meaning that their (post-)processing is still at an experimental stage and needs to be improved.

Not surprisingly, another conclusion of this study is that data resolution and sampling are clearly issues in terms of capturing the large range of frequencies found in the NWMed coastal ocean (and we can easily assume that it is true for many other coastal ocean areas). In particular, the temporal data coverage is a large source of differences between NC statistics computed from different observing systems. A second cause of differences in estimations of NC characteristics appears to be ageostrophic flow, principally the Ekman and inertial currents as measured by the ADCP and HF radars but not represented by the glider (even if they can be partially included through the correction of depth-averaged currents), and altimeter-derived geostrophic currents. Clearly, a multi-data combined approach is a unique way to obtain a complete picture of a dynamical system as complex as the NC.

Finally, it is important to note that improved altimetry data processing and corrections as well as technical innovations lead to an ever increasing number of coastal data points ever closer to the coastline. It raises the question of the calibration and validation of these new data against independent in situ observations. How can we robustly quantify the evolution of the new processing and products? We benefit from the long experience of nadir altimetry technology, widely based on tide gauge sea level observations taken as an independent reference. However, a full understanding and exploitation of the new performances allowed by Ka-band, SAR and SAR-in altimetry techniques, as well as by the use of high-rate altimetry measurements, requires new methods and validation means. We advocate for the fact that only a combination of in situ instruments providing regular cross-shore information along altimetry tracks will allow us to understand and exploit the full capability of altimetry in coastal observing systems and guide its evolution.

Data availability

Altimetry data used in this study were developed, validated by the CTOH/LEGOS, France, and distributed by Aviso+ (, Birol et al., 2017b). Glider and HF radar data are available as part of the MOOSE project (, last access: 20 November 2018, MOOSE, 2018). ADCP data were provided by the DT-INSU data center (, last access: 20 November 2018, DT-INSU, 2018).

Author contributions

This work was carried out by AC as part of her PhD thesis under the supervision of FB and CE. BZ processed the HF radar data, and PT provided the glider data. The paper was prepared with contributions from all coauthors.

Competing interests

The authors declare that they have no conflict of interest.

Special issue statement

This article is part of the special issue “Hydrological cycle in the Mediterranean (ACP/AMT/GMD/HESS/NHESS/OS inter-journal SI)”. It is not associated with a conference.


This study was done with the financial support of the Region Occitanie and the CNES through their PhD funding programs. The ship-mounted ADCP data were kindly provided by the DT-INSU, who conducted the acquisition, management and processing. Altimetry data used in this study were developed, validated and distributed by the CTOH/LEGOS, France. Glider data were collected and made freely available by the Coriolis project ( and programs that contribute. We would like to acknowledge the staff of the French National Pool of Gliders (DT-INSU/CNRS – CETSM/Ifremer) for the sustained glider deployments carried out in the framework of MOOSE. Support was provided by the French Chantier Méditerranée MISTRALS program (HyMeX and MERMeX components) and by the EU projects FP7 GROOM (grant agreement 284321), FP7 PERSEUS (grant agreement 287600), FP7 JERICO (grant agreement 262584) and the COST Action ES0904 EGO (Everyone's Gliding Observatories). HF radar data were funded as part of the French MOOSE Mediterranean observing system program. Finally, we thank the anonymous reviewers for their constructive comments, which helped to improve the quality of the paper.

Edited by: Katrin Schroeder
Reviewed by: two anonymous referees
